0911472255-
Analog output 4..20 mA Connection Connector, M8x1 Angular range min. -45° Angular range max. +45° Resolution 0.01°
-
General attributes
Basic standard EN 61326-1 Enclosure Type per IEC 60529 IP 67 Measuring principle capacitive Polarity reversal protected yes Product group Inclination sensor Protection Class III Short circuit protected yes
-
Electrical attributes
Analog output 4..20 mA Connection type Connector Current draw ≤ 33 mA Effective operating voltage Ue 24 V DC Operating voltage UB max. DC [V] 30 V DC Operating voltage UB min. DC [V] 10 V DC Output curve deviation max. ±0.1° Response time max. 0.7ms
