| Feature |
| - Hermetically Sealed High Accuracy Grade |
| - Robust Design |
| - Compression type |
| - Fully Environmental Protection IP67 |
| - Mateiral : Paint Finished Steel |
| - Braided Shield 4-Wire Round Cable with PVC-Jacket |
| Specification | ||
|
Rated Capacity (R.C.) |
kgf/tf |
20,30,50,100,200,500,800tf |
|
Rated Output (R.O.) |
mV/V |
2.0 ± 0.005 |
|
Zero Balance |
mV/V |
0 ± 0.03 |
|
Combined Error |
% |
0.15 |
|
Repeatability |
% |
0.10 |
|
Creep (30 min) |
% |
0.03 |
|
Temperature effect on |
|
|
|
Zero Value |
% / 10℃ |
0.03 |
|
Output Value |
% / 10℃ |
0.03 |
|
Excitation |
|
|
|
Recommended |
V |
10 |
|
Maximum |
V |
15 |
|
Resistance |
|
|
|
Input |
Ω |
350±3.5 |
|
Output |
Ω |
350±3.5 |
|
Insulation |
MΩ |
>2,000 |
|
Compensated temperature range |
℃ |
-10 ~ +40 |
|
Operating temperature range |
℃ |
-20 ~ +80 |
