| Feature |
| - Tension type |
| - Convenient assembly of shackle and loadcell |
| - Measurement for every industrial temsile load |
| Specification | ||
|
Rated Capacity (R.C.) |
kgf/tf |
10,20,30,50tf |
|
Rated Output (R.O.) |
mV/V |
2.0 Nominal |
|
Zero Balance |
mV/V |
0 ± 0.2 |
|
Combined Error |
% |
0.03 |
|
Repeatability |
% |
0.02 |
|
Creep (30 min) |
% |
0.03 |
|
Temperature effect on |
|
|
|
Zero Value |
% / 10℃ |
0.03 |
|
Output Value |
% / 10℃ |
0.03 |
|
Excitation |
|
|
|
Recommended |
V |
10 |
|
Maximum |
V |
15 |
|
Resistance |
|
|
|
Input |
Ω |
760±40 |
|
Output |
Ω |
700±7 |
|
Insulation |
MΩ |
>2,000 |
|
Compensated temperature range |
℃ |
-10 ~ +40 |
|
Operating temperature range |
℃ |
-20 ~ +80 |
